Technical Parameter:
| Model | CW-400A | CW-500A | CW-600A | CWZD-600C | CW-600C CS | |
| Width of unwinding | 800mm | 1000mm | 1200mm | 1200mm | 1200mm | |
| Pouch-making height | 3 Sides seal/Centerseal seal | 70-380mmxN [N<B] | ||||
| Stand up&zipper bag | 100-580mm[G=70] | |||||
|
Pouch-making Width |
3 Sides seal |
70-380mm |
70-480mm |
70-580mm |
70-580mm |
70-580mm |
|
|
4 Sides seal |
|
|
|
|
100-200mm |
|
|
Center seal |
100-350mm |
100-400mm |
100-450mm |
|
100-450mm |
|
|
Center seal gusset |
100-230mm (G=60x2) 100-280mm [G=60x2] 100-330mm (G=60x2) |
100-330mm [G=60x2] |
|||
|
|
Stand up & zipper bag |
|
|
|
70-260mm |
70-260mm |
|
Speed |
|
100-170pcs/min |
100-170pcs/min |
100-170pcs/min |
100-170pcs/min |
100-170pcs/min |
|
Line speed |
|
35m/min |
35m/min |
35m/min |
35m/min |
35m/min |
|
Total Power |
|
24kw |
2Bkw |
34kw |
40kw |
52kw |
|
Weight of Machine |
|
3500kg |
3850kg |
4300kg |
4500kg |
4800kg |
|
Overall Dimension |
|
8x1.75x1.8m |
8x1.95x1.8m |
8x2.1x1.8m |
10x2.1x2m |
12.5x2.4x2m |
■ Because of the non-stop improving of machine and development of new functions, appearance and specification is subject to change without notice.
